G1 Transformers Ironhide

Free
2 like(s).
LICENSE
CC BY-NC-ND - Attribution - Non Commercial - No Derivatives
By downloading this thing, you agree to abide by the license

G1 Ironhide base on 1984 Transformers TV Series. This is fully articulated model but not transformable.

Video Preview: Here

  • Skale: 1:30 (16.5cm)
  • Coloring can be done by using different color of filament (detail on files name)
  • No Supports
  • Gap tolerance: 0mm balljoint, 0.05mm swivel, 0.05 peg joint
  • Best print orientation for maximum strength result
  • Easy to print
  • Easy to assemble
  • Easy to rescale

More updates: Here

Point of articulation:

  • Neck balljoint
  • Abdomen balljoint
  • Shoulders balljoint
  • Upper arm swivel joint
  • Elbow double balljoint
  • Wrist swivel
  • Waist swivel
  • Hip balljoint
  • Thigh swivel joint
  • Knee doble balljoint
  • Ankle balljoint
  • Toe swivel

Accesories:
- Gun

Important Tips:
- Cutter or sand paper for tolerance adjustment
- Super glue for splited parts
- Use nail polish to fix loose ball joint

Information

Files Type

.stl, .zip, .jpg

3d Print Setting

- Nozzle: 0.4mm
- Layer: 0.15mm
- Filamen: PLA
- Temperature: 195°C
- Speed: 40/s
- Skin/top/bottom: 0.8mm
- Infill: 30%

Disclaimer
  1. Contains small parts and requires high precision. Your printer may need to be properly calibrated for best results.
  2. This model is for fan art purposes only. The original Transformers characters are the property of Hasbro/Takara Tomy. The creator is in no way associated with the owners.
Information on technical characteristics, the delivery set and the appearance of the goods is for reference only and is based on the latest information available at the time of publication.

File (object only) Preview

loading file

List of Files (32)

6_Iron_Body2_ShoulderJoint_BLACK.stl (1024 KiB) -- login
7_Iron_Body3_Chest_RED.stl (65.12 KiB) -- login
8_Iron_Body4_Glass_LIGHTBLUE.stl (29.57 KiB) -- login
9_Iron_Body5_Headlight_GREY.stl (406.33 KiB) -- login
10_Iron_Body6_Abdomen_Grey.stl (680.36 KiB) -- login
11_Iron_Hand1_Shoulders_BLACK.stl (963.75 KiB) -- login
12_Iron_Hand2_Top_RED.stl (708.87 KiB) -- login
13_Iron_Hand3_Elbowjoint_RED.stl (2 MiB) -- login
14_Iron_Hand4_Bottom_RED.stl (808.19 KiB) -- login
15_Iron_Hand5_Fist_BLACK.stl (1024 KiB) -- login
15_Iron_Hand5_Pointed_BLACK.stl (1024 KiB) -- login
15_Iron_Hand5_Relax_BLACK.stl (2 MiB) -- login
15_Iron_Hand5_Salute_BLACK.stl (1024 KiB) -- login
16_Iron_Waist1_Main_GREY.stl (640.51 KiB) -- login
17_Iron_Waist2_Side_GREY.stl (150.08 KiB) -- login
18_Iron_Waist3_Front_GREY.stl (560.43 KiB) -- login
19_Iron_Waist4_Hips_GREY.stl (1024 KiB) -- login
20_Iron_Leg1_Hip_GREY.stl (872.15 KiB) -- login
21_Iron_Leg2_Thigh_GREY.stl (449.69 KiB) -- login
22_Iron_Leg3_Kneejoint_GREY.stl (1024 KiB) -- login
23_Iron_Leg4_Mainleft_RED.stl (1024 KiB) -- login
23_Iron_Leg4_Mainright_RED.stl (1024 KiB) -- login
24_Iron_Leg5_Anklejoint_RED.stl (1024 KiB) -- login
25_Iron_Leg6_Bottom_RED.stl (960.04 KiB) -- login
26_Iron_Leg7_Bottom2_RED.stl (484.65 KiB) -- login
27_Iron_Gun_GREY.stl (2 MiB) -- login
Ironhide_Instruction.zip (457.15 KiB)
