G1 Transformers Windcharger

Free
9 like(s).
LICENSE
CC BY-NC-ND - Attribution - Non Commercial - No Derivatives
By downloading this thing, you agree to abide by the license

G1 Windcharger form 1984 Transformers TV Series, fully articulated model but not transformable.

  • Skale: 1:30 (10cm)
  • Coloring can be done by using different color of filament (detail on files name)
  • No Support
  • Gap tolerance: 0mm balljoint, 0.05mm swivel, 0.05 peg joint
  • Best print orientation for maximum strength result
  • Easy to print
  • Easy to assemble
  • Easy to rescale

More updates: Here

Point of articulation:
1. Neck ball joint
2. Abdomen ball joint
3. Shoulders ball joint
4. Upper arm swivel joint
5. Elbow ball joint
6. Wrist swivel
7. Waist swivel
8. Hip ball joint
9. Thigh swivel joint
10. Knee ball joint
11. Ankle ball joint

Accesories :
-Gun

IMPORTANT TIPS:
- Use Nail Polish to fix loose ball joint
- Cutter or sand paper for tolerance adjustment
- Use super glue for split parts

Information

Files Type

.stl, .zip, .jpg

3d Print Setting

Nozzle: 0.4mm
Layer: 0.15mm (0.1mm for the head)
Filamen: PLA
Temperature: 200°C
Speed: 40/s
Skin/top/bottom: 0.8mm
Infill: 25%

Disclaimer
  1. Contains small parts and requires high precision. Your printer may need to be properly calibrated for best results.
  2. This model is for fan art purposes only. The original Transformers characters are the property of Hasbro/Takara Tomy. The creator is in no way associated with the owners.
Information on technical characteristics, the delivery set and the appearance of the goods is for reference only and is based on the latest information available at the time of publication.

File (object only) Preview

loading file

List of Files (24)

6_Wind_Body2_Backpack_RED.stl (142.95 KiB) -- login
7_Wind_Body3_Shouldersjoint_BLACK.stl (1024 KiB) -- login
8_Wind_Body4_Abdomen_DARKBLUE.stl (673.52 KiB) -- login
9_Wind_Waist1_Main_DARKBLUE.stl (208.19 KiB) -- login
10_Wind_Waist2_Side_RED.stl (19.81 KiB) -- login
11_Wind_Waist3_Hip_DARKBLUE.stl (1024 KiB) -- login
12_Wind_Hand1_Shoulder_RED.stl (804.57 KiB) -- login
13_Wind_Hand2_ShoulderSide_BLACK.stl (8.29 KiB) -- login
14_Wind_Hand3_Bicep_RED.stl (1024 KiB) -- login
15_Wind_Hand4_Forearm_RED.stl (622.54 KiB) -- login
16_Wind_Hand5_Fist_RED.stl (2 MiB) -- login
17_Wind_Leg1_Thigh_SILVER.stl (1024 KiB) -- login
18_Wind_Leg2_Shin_SILVER.stl (2 MiB) -- login
19_Wind_Leg3_Foot_RED.stl (939.93 KiB) -- login
20_Wind_Leg4_FootFront_BLACK.stl (163.36 KiB) -- login
21_Wind_Gun_DARKBLUE.stl (249.98 KiB) -- login
22_Wind_HandCannon1_RED.stl (135.53 KiB) -- login
23_Wind_HandCannon2_SILVER.stl (200.18 KiB) -- login
Windchargerfiles.zip (275.7 KiB)
